Powder Coat 12000lbs Heavy Duty Pintle Hitch Receiver
Product Details:
| Place of Origin: | Zhejiang , China |
| Brand Name: | YEEDA |
| Certification: | CE |
| Model Number: | YD39-009,YD39-010,YD39-011 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 100 PCS |
|---|---|
| Packaging Details: | Carton Box |
| Delivery Time: | 30-45DAYS |
| Payment Terms: | T/T |
| Supply Ability: | 5000 Pcs/Month |
|
Detail Information |
|||
| Model No.: | YD39-009,YD39-010,YD39-011 | Name: | Pintle Combination Ball |
|---|---|---|---|
| Material: | Steel | Process: | Hot Forging |
| Ball Capacity: | 2000lb,7000lb,12000lb | Body Capacity: | 12,000LBS |
| Surface: | Black Powder Coat | Application: | Trailer |
| Parts: | Trailer Suspension | MOQ: | 100 Pcs |
| High Light: | 12000 lbs Heavy Duty Pintle Hitch Receiver,Powder Coat Heavy Duty Pintle Hitch Receiver,12000 lbs Combination Pintle Hook Ball Hitch |
||
Product Description
Heavy Duty Towing Coupled Trailer Hitch Pintle Hook
- In agriculture, construction and even military applications, pintle hitches are the trusted product of specialized towing. They are notorious for their high weight capacity and simple design. The basic pintle hitch is essentially a hook and loop, with the hook attached to the vehicle and the loop mounted on the trailer. Because of their simple design, pintle hitches are able to have thicker metal construction and more secure coupling. Tow Ready combination ball and pintle hitches combine both a pintle hook and a standard trailer ball to give you a more complete towing option on your heavy-duty truck or SUV.
- This particular receiver-mount ball and pintle hook is designed to insert into any 2" x 2" receiver tube. With a trailer ball capacity of 7,000 lbs., it offers a solid complement to any class 4 trailer hitch (NOTE: Never exceed the lowest weight capacity of any towing component; i.e. the vehicle, hitch, trailer, etc).
- The pintle hook fits any lunette ring with a 2" inside eye diameter, while the trailer ball can be coupled to any 2" coupler. The heavy-duty towing done with pintle hitches brings with it a certain amount of wear and tear on your towing equipment, and to prepare for this, Tow Ready uses a quality finish on all of our pintle mounts, lunette eyes and combination pintle hitches.
Specification:
| Part No. | Ball Size | Ball Capacity (LBS) | Body Capacity (LBS) | NW | Finish | Shank | ||||
| YD39-009 | 1-7/8" | 2,000 | 12,000 | 17.64 LBS (8 KG) | Black powder coat | Solid | ||||
| YD39-010 | 2" | 7,000 | ||||||||
| YD39-011 | 2-5/16" | 12,000 | ||||||||
- Chain with Hitch Ball Chrome (Zinc/Black powder-coat / Stainless Steel) , 1 PC.
