2 Ton Cross Beam Adaptor: 590-930mm, Rubber Plates for Auto Repair/Lifting

Large Image : 2 Ton Cross Beam Adaptor: 590-930mm, Rubber Plates for Auto Repair/Lifting

Product Details:

Place of Origin:	Zhejiang，China
Brand Name:	YEEDA
Certification:	CE
Model Number:	YD03-006

Payment & Shipping Terms:

Minimum Order Quantity:	50pcs
Packaging Details:	Carton Box or Crate
Delivery Time:	30-45DAYS
Payment Terms:	T/T
Supply Ability:	500PCS/MONTH

Contact Now

Detailed Product Description

Product Name:	YD03-006 2 TON CROSS BEAM ADAPTOR	Capacity:	2 Ton (approx. 2000 Kg)
Working Range:	590-930 Mm (cross Beam Adaptation Length)	Height Adjustment:	0-55 Mm (height Adjustment Of Rubber Lifting Plates)
Net Weight:	11 Kg	Package Size:	72.5 Cm × 13 Cm × 14 Cm
Highlight:	2 ton cross beam adaptor for lifting , rubber plate cross beam adaptor , 590-930mm auto repair adaptor

YD03-006 2 Ton Cross Beam Adaptor: 590-930mm, Rubber Plates for Auto Repair/Lifting

Product Specifications

Parameter Category	Specific Value
Product Name	YD03-006 2 TON CROSS BEAM ADAPTOR
Brand Reference	Compatible with most Pittsburgh floor jacks
Model No.	YD03-006
Capacity	2 ton (approx. 2000 kg)
Working Range	590-930 mm (cross beam adaptation length)
Height Adjustment	0-55 mm (height adjustment of rubber lifting plates)
Net Weight	11 kg
Gross Weight	12 kg
Package Size	72.5 cm * 13 cm * 14 cm
20ft Container Load	1720 pcs
Core Configuration	Heavy-duty welded steel cross beam, adjustable rubber lifting plates, safety chain, adaptive saddle interface, anti-slip contact panel
Core Functions	2-ton stable load-bearing, 590-930mm wide-range adaptation, 0-55mm height fine adjustment, rubber plates for undercarriage damage prevention, safety chain for anti-falling, compatible with multi-brand floor jacks
Applicable Equipment	Most Pittsburgh floor jacks, general floor jacks with removable saddles

Product Details

The YD03-006 2 TON CROSS BEAM ADAPTOR is an auxiliary tool designed specifically for extending the load-bearing capacity and adaptability of floor jacks. It addresses common issues with traditional jacks such as narrow contact points, potential undercarriage damage, and limited vehicle adaptation.

2-Ton High Load-Bearing + Welded Steel Structure: Constructed from Q235 low-carbon steel with 8mm thickness cross beam and reinforced welded joints. Can withstand 2-ton rated load with ≤0.3mm deformation and short-term 2.2-ton overload pressure.
590-930mm Wide-Range Adaptation: Adjustable width supports small sedans (590-700mm), compact sedans (700-800mm), and compact SUVs (800-930mm), covering 95% of family vehicles.
Rubber Lifting Plates + Safety Chain: 15mm thick rubber plates provide 80cm² contact area with ≥0.85 friction coefficient. Includes 2-ton capacity safety chain for anti-falling protection.
0-55mm Height Fine Adjustment: Precise height adjustment via bottom knob rotation, suitable for low-slung vehicles (0-20mm) and high-clearance SUVs (30-55mm) with ±2mm accuracy.

Application Scenarios

Auto Repair Shops: Efficiently handles multiple vehicle types (sedans to SUVs) with 590-930mm width adjustment and 2-ton capacity.
Auto Maintenance Stores: Provides even weight distribution for side/front/rear lifting up to 930mm height, ideal for gearbox maintenance and undercarriage work.
Personal Garages: 11kg lightweight design for easy handling; protects undercarriage during DIY maintenance like oil changes and tire rotations.
Auto Beauty Shops: Height adjustment adapts to various vehicles for thorough undercarriage cleaning and rust prevention.

Frequently Asked Questions

Q1: Can the 2-ton load-bearing adapt to a compact SUV weighing 1.9 tons?

A1: Yes. The product has a 10% safety margin (actual safe load ≈2.2 tons). Adjust width to 800-930mm for proper contact with SUV undercarriage beams and use the safety chain for secure lifting.

Q2: How to confirm if my floor jack is compatible with this adapter?

A2: Verify two parameters: 1) Your jack has a removable saddle (most Pittsburgh and general floor jacks qualify); 2) Jack's rated load is ≥2 tons. Installation takes ≤1 minute with 98% compatibility.

Q3: Can the rubber lifting plates be replaced separately after wear?

A3: Yes. The screw-fixed design allows easy replacement in ≈3 minutes per plate using standard tools, with replacement parts available through brand after-sales service.

Q4: When lifting one side of the vehicle, is the adapter's stability guaranteed?

A4: Yes. The "thickened middle + anti-slip ends" design evenly distributes weight. Rubber plates (≥0.85 friction coefficient) and safety chain prevent sliding and tipping, even at 930mm height.
