6000-LB Portable Auto Lift: 72"H, 3HP/CETL, for Car/Truck Repair in US/Canada

Large Image : 6000-LB Portable Auto Lift: 72"H, 3HP/CETL, for Car/Truck Repair in US/Canada

Product Details:

Place of Origin:	Zhejiang，China
Brand Name:	YEEDA
Certification:	CE
Model Number:	YD07-03

Payment & Shipping Terms:

Minimum Order Quantity:	50pcs
Packaging Details:	Carton Box or Crate
Delivery Time:	30-45DAYS
Payment Terms:	T/T
Supply Ability:	500PCS/MONTH

Contact Now

Detailed Product Description

Parameter Category Specific Value Product Name:	YD07-003 6000 LB Portable Single Post Auto Lift	Brand Association:	Brand Association
Lift Capacity:	6000 LB (approx. 2722 KG)	Lifting Height:	Lifting Height (no Adapters): 72" (approx. 182.9 Cm) Height On The Ground (no Pads): 5" (approx. 12.7 Cm)
Assembled Overall Dimension:	112"L × 94"W × 103"H (approx. 284.5×238.8×261.6 Cm)	Hydraulic Motor Pump Parameters:	Power: 110V/220V, 3HP No-load Speed: 3420 RPM Working Pressure: 2650 PSI Tank Capacity: 11 L
Highlight:	6000-LB portable car lift , 3HP truck repair lift , 72-inch motorcycle lift bench

6000-LB Portable Auto Lift: 72"H, 3HP/CETL, for Car/Truck Repair in US/Canada

Product Specifications

Parameter Category	Specific Value
Product Name	YD07-003 6000 LB Portable Single Post Auto Lift
Model No.	YD07-003
Brand Association	TMGINDUSTRIAL
Lift Capacity	6000 LB (approx. 2722 KG)
Lifting Height	Lifting height (no adapters): 72" (approx. 182.9 cm) Height on the ground (no pads): 5" (approx. 12.7 cm)
Space Parameters	Height Clearance: 67" (approx. 170.2 cm) Distance (front to rear lift pads): 28.75"-83.75" (approx. 73-212.7 cm) Distance (rear lift pads): ≥53" (approx. 134.6 cm) Distance (two front lift pads): 55"-91.5" (approx. 139.7-232.4 cm)
Assembled Overall Dimension	112"L * 94"W * 103"H (approx. 284.5238.8261.6 cm)
Hydraulic Motor Pump Parameters	Power: 110V/220V, 3HP No-load speed: 3420 RPM Working pressure: 2650 PSI Tank capacity: 11 L
Certification Standard	CETL Certified (for Canada and USA markets)
Package Information	Packaging: Wooden crate for shipping Shipping dimension: 110"42"43" (approx. 279.4106.7109.2 cm) Shipping weight: 2400 LB (approx. 1088.6 kg)
Core Configuration	Pallet-jack style low-profile body, 10.5"*12.5" heavy-duty structural column, chain-drive carriage, retractable reach arms (with height screw-up pads), mechanical single-point self-lock, 8 height adapters, CETL-certified hydraulic pump
Applicable Objects	Family cars (e.g., Toyota Camry, Volkswagen Magotan), light-duty trucks (e.g., Foton Xiangling, JMC Shunda), small SUVs (e.g., Honda CR-V, Toyota RAV4) (weight ≤2722 KG)

Product Details

The YD07-003 6000 LB Portable Single Post Auto Lift is professional equipment designed for flexibility and compliance in auto maintenance in Canada and the USA. It addresses common issues with traditional lifts such as inconvenient movement, difficulty adapting to high-chassis vehicles, and lack of certification.

Key Features:

6000 LB Heavy Load + Heavy-Duty Structural Column

Features a 10.5"*12.5" heavy-duty structural column made of Q355 low-carbon alloy steel with 12 mm wall thickness. Key connection parts are welded after forging and reinforcement, with 510 MPa tensile strength. Maximum deformation of only 0.3 mm under rated load. Surface treated with sandblasting rust removal and double-layer electrostatic painting (80 μm coating thickness) for corrosion resistance and 15+ year service life.
72" High Lifting Height + Multi-Dimensional Adjustment

72" lifting height without adapters (approx. 182.9 cm) for in-depth chassis maintenance. Includes 8 height adapters (5-15 cm thickness options) for additional height adjustment. Ultra-low 5" ground height (approx. 12.7 cm) accommodates low-stance vehicles. Retractable reach arms support 55"-91.5" spacing adjustment, adapting to 95% of common vehicle wheelbases.
Pallet-Jack Style Mobility + Chain Drive

Innovative pallet-jack design with 4 high-load-bearing swivel wheels (600 KG capacity each) for easy movement. 1.8 meter turning radius works in compact 15 m² spaces. Chain-drive technology with 3HP hydraulic pump provides 10 mm/sec lifting speed (12 minutes for full height), 40% more efficient than screw-driven lifts. Maintains 2650 PSI working pressure even at -10℃.
CETL Certification + Dual Safety Protection

CETL certified for Canada and USA markets. Features mechanical single-point self-lock with 8 locking gears (10"-72" heights) and anti-slip adjustment pads. Load-bearing redundancy reaches 120% of rated capacity for enhanced safety.
