RYAN Cable Ties: High Tensile Strength Nylon Fasteners
Premium nylon cable ties designed for electrical, industrial, construction, and home applications. Available in three strength grades with tensile capacities ranging from 55-114KGS (120-250LBS).
Product Specifications
RYAN Cable Ties are manufactured to international standards in three duty classifications:
Light Heavy Duty Cable Ties (55KGS/120LBS)
| Model No. |
Width (mm) |
Length (mm) |
Length (Inch) |
Bundle Diameter (mm) |
Tensile (LBS) |
Tensile (KGS) |
| YD80-001-A8*200 | 7.6 | 200 | 8" | 3-50 | 120 | 55 |
| YD80-001-A8*250 | 7.6 | 250 | 10" | 4-63 | 120 | 55 |
| YD80-001-A8*300 | 7.6 | 300 | 11.8" | 4-82 | 120 | 55 |
| YD80-001-A8*350 | 7.6 | 350 | 13.7" | 4-90 | 120 | 55 |
| YD80-001-A8*380 | 7.6 | 380 | 15.2" | 4-100 | 120 | 55 |
| YD80-001-A8*400 | 7.6 | 400 | 15.7" | 4-105 | 120 | 55 |
| YD80-001-A8*450 | 7.6 | 450 | 17.7" | 4-118 | 120 | 55 |
| YD80-001-A8*500 | 7.6 | 500 | 19.8" | 4-150 | 120 | 55 |
| YD80-001-A8*550 | 7.6 | 550 | 21.6" | 4-160 | 120 | 55 |
Heavy Duty Cable Ties (80KGS/176LBS)
| Model No. |
Width (mm) |
Length (mm) |
Length (Inch) |
Bundle Diameter (mm) |
Tensile (LBS) |
Tensile (KGS) |
| YD80-001-A10*400 | 9 | 400 | 15.7" | 8-105 | 176 | 80 |
| YD80-001-A10*450 | 9 | 450 | 17.7" | 10-125 | 176 | 80 |
| YD80-001-A10*500 | 9 | 500 | 19.8" | 10-150 | 176 | 80 |
| YD80-001-A10*550 | 9 | 550 | 21.6" | 10-160 | 176 | 80 |
| YD80-001-A10*600 | 9 | 600 | 23.6" | 10-170 | 176 | 80 |
| YD80-001-A10*650 | 9 | 650 | 25.6" | 10-190 | 176 | 80 |
| YD80-001-A10*720 | 9 | 720 | 28.3" | 10-205 | 176 | 80 |
| YD80-001-A10*760 | 9 | 760 | 30" | 10-225 | 176 | 80 |
| YD80-001-A10*800 | 9 | 800 | 31.5" | 10-240 | 176 | 80 |
| YD80-001-A10*920 | 9 | 920 | 36.8" | 10-265 | 176 | 80 |
| YD80-001-A10*1000 | 9 | 1000 | 39.3" | 10-295 | 176 | 80 |
| YD80-001-A10*1100 | 9 | 1100 | 44" | 10-310 | 176 | 80 |
| YD80-001-A10*1220 | 9 | 1220 | 48.8" | 10-340 | 176 | 80 |
Extraheavy Duty Cable Ties (114KGS/250LBS)
| Model No. |
Width (mm) |
Length (mm) |
Length (Inch) |
Bundle Diameter (mm) |
Tensile (LBS) |
Tensile (KGS) |
| YD80-001-A12*500 | 12 | 500 | 19.8" | 14-150 | 250 | 114 |
| YD80-001-A12*550 | 12 | 550 | 21.6" | 14-160 | 250 | 114 |
| YD80-001-A12*600 | 12 | 600 | 23.6" | 14-170 | 250 | 114 |
| YD80-001-A12*650 | 12 | 650 | 25.6" | 14-190 | 250 | 114 |
Packaging: 10 pieces per package (10PC). Made from high-quality nylon for durability, wear resistance, and aging resistance. Performs reliably in extreme temperatures (-40°C to 85°C) and humid conditions.
Key Features
- Branded "RYAN" identification for authenticity
- Precision-engineered self-locking mechanism
- Smooth surface protects fastened objects
- Chemical resistant to oils, solvents, and acids
- Multiple length options for versatile applications
- RoHS compliant for environmental safety
Applications
Electrical & Electronics
Organize internal wiring in computers, servers, and household electrical systems. Light duty models ideal for small-diameter cables.
Industrial Manufacturing
Secure cables and hoses in automotive engines. Fasten heavy components in machinery transport and assembly.
Construction
Fix power and communication cables to structural elements. Stabilize HVAC ducting and piping systems.
Home & Office
Manage entertainment system cables. Install holiday decorations and home improvement projects.
Frequently Asked Questions
Can RYAN Cable Ties be reused?
No, they are designed for single-use to maintain tensile strength and safety. The self-locking mechanism provides permanent fastening.
What temperature range can they withstand?
-40°C to 85°C (-40°F to 185°F). Performance may vary in extreme conditions - consult our team for specific applications.
How to choose the right size?
Consider both object circumference and weight. Select a length exceeding the circumference and match tensile strength to the weight requirements.
Are they environmentally friendly?
Yes, made from recyclable nylon. RoHS certified with no hazardous substances. Please dispose responsibly.
What certifications do they have?
RoHS compliant. Rigorously tested for tensile strength, temperature resistance, and chemical resistance.
