Pneumatic Accessories: Brass Quick Connectors/Tees + 140PSI for Factory/Auto/DIY Pipes

Large Image : Pneumatic Accessories: Brass Quick Connectors/Tees + 140PSI for Factory/Auto/DIY Pipes

Product Details:

Place of Origin:	Zhejiang，China
Brand Name:	YEEDA
Certification:	CE
Model Number:	YD32-016

Payment & Shipping Terms:

Minimum Order Quantity:	50pcs
Packaging Details:	Carton Box or Crate
Delivery Time:	30-45DAYS
Payment Terms:	T/T
Supply Ability:	500PCS/MONTH

Contact Now

Detailed Product Description

Highlight:

brass quick connectors for pneumatic pipes

140PSI pneumatic tees for auto DIY

motorcycle lift bench pneumatic accessories

Pneumatic Accessories: Brass Quick Connectors/Tees + 140PSI for Factory/Auto/DIY Pipes

Product Specifications

Accessory Category	Specific Specification	Core Parameters
1. Pneumatic Quick Connector	Male-female plug-in quick connector	Interface Specification: G1/4", G3/8", G1/2" (3 options); Material: Brass (H59 environmental brass) + engineering plastic; Working Pressure: 0-140 PSi (approx. 0-9.65 bar); Temperature Resistance Range: -20-80℃; Sealing Method: Nitrile rubber seal ring (anti-leakage)
2. Pneumatic Tee Joint	Equal-diameter tee joint	Interface Specification: G1/4", G3/8", G1/2" (matching pipe diameter); Material: Brass (integrally forged, no welds); Working Pressure: 0-160 PSi (approx. 0-10.34 bar); Applicable Pipeline: PU/nylon pneumatic hose (inner diameter 6-12mm)
3. Pneumatic Shut-Off Valve	Manual knob-type shut-off valve	Interface Specification: G1/4", G3/8" (2 options); Material: Brass valve body + plastic knob; Working Pressure: 0-150 PSi (approx. 0-10.34 bar); Switch Life: ≥5000 times; Protection Class: IP54 (dustproof and waterproof)
4. Pneumatic Pipe Clip	Fixed pipe clip	Applicable Pipe Diameter: 6mm, 8mm, 10mm, 12mm (4 specifications); Material: PA66 engineering plastic + stainless steel screws; Installation Method: Drilling and fixing on wall/tabletop; Load-Bearing Capacity: ≤5kg (preventing pipeline sagging)
5. Complete Set	Pneumatic pipeline basic accessory set	Included Accessories: Quick connectors (4 sets, 2 males and 2 females each), tee joints (2 pieces), shut-off valves (2 pieces), pipe clips (10 pieces); Carton Specification: 35×25×18cm (30 sets per carton); Total Weight: 0.8kg/set (including packaging); Applicable Scenarios: Pneumatic pipeline construction, maintenance, modification

General Basic Parameters

Parameter Category

Specific Description

Product Positioning

Exclusively designed for pneumatic pipeline construction, maintenance, and modification scenarios, it mainly serves factory pneumatic production lines (pipeline expansion), auto repair shops (workstation pipeline layout), DIY pneumatic operations (household air compressor pipeline construction), and equipment maintenance teams (pipeline fault repair).

Structure & Material

Common Material Advantages: Core pressure-bearing components are made of H59 environmental brass, which is high-pressure resistant (no deformation under ≥140 PSi), resistant to compressed air corrosion (no rust after 120-hour salt spray test).
Accessory Details: Quick Connector has built-in one-way valve; Tee Joint is integrally forged; Shut-Off Valve has anti-slip texture design; Pipe Clip is anti-aging.
Universal Compatibility: All accessory interfaces comply with ISO standard threads (G threads), compatible with most air compressors, pneumatic tools, and hoses on the market.

Product Details

All-Brass Core Components, High-Pressure Resistant & Corrosion-Proof

High-Pressure Resistance: Quick connectors, tees, and shut-off valves can all withstand ≥140 PSi high pressure without bursting risks.
Corrosion Resistance: The oxide layer on the brass surface can isolate moisture and impurities in compressed air, avoiding seal failure caused by internal rust.
Precision Machining: Thread precision meets ISO 228 standards with nitrile rubber seals, air leakage after installation is ≤0.1 L/min.

Full Coverage of Multi-Specifications, Adapting to Most Scenarios

Interface Specifications: Quick connectors, tees, and shut-off valves provide G1/4", G3/8", and G1/2" options.
Pipe Diameter Adaptation: Pipe clips cover 6-12mm common pneumatic hose diameters.
Multi-Type Accessory Combination: From pipeline construction to fixing, one set of accessories is sufficient.

Easy Installation, Accessible to Beginners

Tool-Free/Less-Tool Installation: Most accessories can be installed without professional tools.
Detailed Design: Dust cap for female quick connector, anti-slip texture on shut-off valve knob, adjustable hole position of pipe clip.

Application Scenarios

Pipeline Expansion of Factory Pneumatic Production Lines

Install tee joints on main pipeline to split branch pipelines
Connect equipment with quick connectors
Control air flow with shut-off valves
Fix pipelines with pipe clips

Workstation Pipeline Layout in Auto Repair Shops

Lead main pipeline from air compressor and split to workstations with tees
Install shut-off valves and quick connectors at each workstation
Fix nylon hose along the wall with pipe clips

Household Air Compressor Pipeline Construction for DIY

Connect air compressor and PU hose with quick connector
Split branches with tee and install shut-off valves
Fix PU hose to wall with pipe clips

Frequently Asked Questions

Q1: Air leakage still occurs after inserting the quick connector. What is the reason?

Check insertion depth - ensure male connector is fully inserted
Inspect seal - replace aging or deformed seal ring
Clean impurities - blow clean connectors with compressed air

Q2: The tee joint produces air flow noise under high pressure. Is it due to excessive pressure or installation issues?

Check pressure adaptation - adjust air compressor pressure if needed
Inspect installation sealing - tighten threads or add Teflon tape
Verify pipeline matching - ensure tee interface matches hose specification

Q3: The pipeline still sags after being fixed with pipe clips. How to solve it?

Check pipe clip specification - ensure matching hose diameter
Adjust installation spacing - reduce to 50-60cm if needed
Optimize installation method - use rubber pad for uneven walls

Q4: Can a small household air compressor (G1/4" interface) use this set of accessories?

Fully compatible with no additional adapter required
Household air compressor output pressure is mostly 80-100 PSi, well within specifications
Set pipe clip spacing to 60cm and cover quick connector when idle
